 Airport / FBO Information
KI39       MADISON       RICHMOND       KY
  Time Zone: ET
Lat: N 3737.9     Long: W 08419.9     Elev: 1002     Var: +01  Longest Runway: 4500
     AWOS: 119.62        CTAF: 122.8

FBO info for KI39:
SPECTRUM AVIATION Ph: 859-986-3913 Fax: 859-986-3128 Freq: 122.8
AWOS Ph: 859-985-5969
-
Freq: 119.62


FBO's at nearby airports who want your business:

 Runway & Approach Info
  Rwy
    Length
  Land Dist Avail
  Approach*
    Rwy
Length
  Land Dist Avail
 Approach*
18
4500x100  4410'


36
  4500x100  4500'

 * only ILS, LOC, LDA, and SDF approaches to a specific runway are shown

Runway Weight Capability   (lbs.)
Runway IDSingle WheelDouble WheelDouble Tandem WheelDual Double Wheel
18/3612,500N/AN/AN/A


Database effective date: 07/31/2008

Facility Name: MADISON
City Name: RICHMOND
County: MADISON
State abbrev: KY
State Name: KENTUCKY

Ownership: PUBLICLY OWNED
Use: OPEN TO THE PUBLIC
Owner's Name: MADISON AIRPORT BOARD INC
Address: PO BOX 1110
 BEREA, KY 40403
Owner's Phone: 859-986-8418

Manager's Name: NATHAN T. HOSKINS; AIRPORT BOARD CHAIRMAN: CLIFFORD KERBY.
Address: 124 MADISON AIRPORT RD.
 RICHMOND, KY 40475
Phone: 859-986-3913

FAA Region: SOUTHERN
FAA Field Office: MEM

Click here to submit your photo
Area Map of I39
Click Here for Rand McNally Map of I39

Sunrise / Sunset times for:
MADISON
Date: Sunrise Sunset
July 01, 2008 6:2021:03
August 01, 2008 6:4220:45
September 01, 2008 7:0820:05
October 01, 2008 7:3419:19
November 01, 2008 8:0318:38
December 01, 2008 7:3417:19
January 01, 2009 7:5317:30
February 01, 2009 7:4118:01
March 01, 2009 7:0918:31
April 01, 2009 7:2320:00
May 01, 2009 6:4220:27
June 01, 2009 6:1820:53

 Airport Facilities
Airport Attendance Schedule: 7 Days A Week 0800-1700
Airport Status: OPERATIONAL (This Status can change at any time - please check NOTAMS)
Airport Lighting Schedule: DUSK-DAWN; ACTVT MIRL, PAPI, REIL RY 18/36 - CTAF.
Airport Storage Available: Tie Downs, Hanger
Extra Services Available: NONEFlight Instruction, Aircraft Rental
Wind Indicator: YES - (lighted)
Control Tower: NO
CTAF Frequency: 122.800
Unicom Frequency: 122.800
Rotating Beacon Color: CLEAR-GREEN (Light Land Airport)
Segmented Circle: YES
Landing Fee: NO

Airport Services
Type of Fuel Available: Grade 100LL, JET A (freeze point -40C)
Airframe Repair Service: MAJOR
Power Plant Repair Service: MAJOR

Geographic Data
Latitude: N3737.9   Longitude: W08419.9  (ESTIMATED)
Arpt Elevation: 1002ft (SURVEYED)
Magnetic Variation: 01W
8 miles SW of RICHMOND
Traffic Pattern Altitude:
Sectional Chart: CINCINNATI

  Aircraft Data
Operations (reported)
YearlyAvg. Daily
General Aviation transient: 670018
General Aviation Local: 680019
Air Taxi: 14004
Commercial: 00
Commuter: 00
Military: 4001
Aircraft based on Field
General Aviation Singles: 33
General Aviation Multi: 4
Jet Aircraft: 0
General Aviation Helicopters: 0
Military Aircraft: 0
Gliders: 0
Ultralights: 0

  FAA Services
FSS on field: NO
FSS tie-in: LOUISVILLE
FSS Phone: 1-800-WX-BRIEF
Who issues Notams: LOU
Notam D service at airport: YES
ARTCC Name: INDIANAPOLIS

  Federal Status
Airport Certification:
Aircraft Rescue & Firefighting Index: None
Airport of Entry: No
Custom Landing Rights: No
Joint Civil/Military: No
Military Landing rights: YES

Runway Identification: 18/36
Length: 4500 ft
Width: 100 ft
Surface: ASPHALT-GOOD CONDITION
Edge lights: Medium Intensity



Runway: 18

Runway: 36
Mag heading:  176ºMag heading:  356º
Rwy Slope:  .78% UpRwy Slope:  -.78% Down
Approach:  Approach:
Pattern:  Left TrafficPattern:  Left Traffic
Markings:  NONPRECISION INSTRUMENTMarkings:  NONPRECISION INSTRUMENT
Marking Condition:  GOODMarking Condition:  GOOD
Arresting Dev:  Arresting Dev:
Lat & Long:  N3738.2  W08420.0Lat. & Long.:  N3737.5  W08419.9
Elev:  966.7 ft. MSLElev:  1002.0 ft. MSL
TCH:  22 ft. AGLTCH:  24 ft. AGL
Visual Glide Path:  3.00 degreesVisual Glide Path:  3.00 degrees
Displaced Threshold:  90 feetDisplaced Threshold:  No
Touchdown Zone:  YESTouchdown Zone:  YES
Touchdown Elev.:  985 feetTouchdown Elev.:  1002 feet
Visual Glide Slope:  4-Light PAPI on LEFT side of RunwayVisual Glide Slope:  4-Light PAPI on LEFT side of Runway
RVR Equipment:  RVR Equipment:
RVV Equipment:  NORVV Equipment:  NO
Approach Lights:  Approach Lights:
REIL:  YESREIL:  YES
Centerline Lights:  NOCenterline Lights:  NO
Touchdown lights:  NOTouchdown lights:  NO
Runway Catagory:  OTHER THAN UTILITY RUNWAY WITH A NON PRECISION APPROACH HAVING VISIBILITY MINIMUNS GREATHER THAN 3/4 MILERunway Catagory:  OTHER THAN UTILITY RUNWAY WITH A NON PRECISION APPROACH HAVING VISIBILITY MINIMUNS GREATHER THAN 3/4 MILE
Obstructions:  TREESObstructions:  TREES
Marked:  NOT Marked/LightedMarked:  NOT Marked/Lighted
Clearance slope:  5:1; APCH RATIO 29:1 TO DSPLCD THLD.Clearance slope:  20:1
Obstruction height:  12 feet AGLObstruction height:  15 feet AGL
Dist. from runway:  260 feetDist. from runway:  500 feet
Centerline offset:  180 right of centerlineCenterline offset:  0B
Comments:  Comments:

Remarks
  • OPERATOR: ALGAN LAKE - PHONE 859-986-3913 OR 3128.

    • Federal Agreements
  • NATIONAL PLAN OF INTEGRATED AIRPORT SYSTEMS (NPIAS)
  • GRANT AGREEMENTS UNDER FAAP/ADAP/AIP
  • ASSURANCES PURSUANT TO TITLE VI, CIVIL RIGHTS ACT OF 1964

    • Airport Inspection Data
    Airport Inspected:: STATE - performed by STATE AERONAUTICAL PERSONNEL
    Inspection Date: 05/03/2006



    Airport Communications & Frequencies:
    CTAF Frequency: 122.800
    Unicom Frequency: 122.800


    LEXINGTON Primary Approach Frequencies:
    120.15
    259.3
    LEXINGTON Primary Departure Frequencies:
    120.15
    259.3
